Darton M.I.D. Cylinder Sleeves – Set of 5

SKU: 800-550

Darton ductile iron cylinder sleeves for high-performance engine builds.

$989.00

2 in stock

Your Volvo Experts
  • Knowledgable Staff
  • Hand-picked products
  • World-class customer service

Description

Darton cylinder sleeves offer maximum strength for high-performance engine builds. If you want to run higher compression ratios, max boost, and make more power, you need to have the strongest cylinders possible. Unfortunately the stock cylinder liners cannot stand up the increased rigors of higher than stock boost and power levels. That means replacing the stock cylinder liners with Darton M.I.D. Cylinder Sleeves for a nearly bulletproof block.

Darton Sleeve Install Volvo 5 Cylinder

Darton M.I.D. Sleeves feature:

  • Cast iron performance in an aluminum block
  • Improved block integral strength
  • Improved cooling
  • Kits can be installed by your local machine shop
  • “Wet sleeve” replace-ability
  • Full installation manual available on website
  • Increased horsepower output potential
  • High boost and horsepower potential
  • Superior oil and compression control
  • Superior cylinder sealing and ring wear
  • Street or strip application
  • Bulletproof Darton ductile iron
  • 130,000-psi tensile strength

Specs:

Bore O.D. Wall Overall Length Flange Thickness Flange Diameter Bore Size
3.260 3.750 0.245 5.400 0.400 4.470 83mm-85mm MAX

Additional information

Weight 18 lbs
